HydraTite® Internal Pipe Joint Seal

HydraTite® repairs deteriorating pipes from the INSIDE with no excavation. Great for emergency repairs. Used successfully for over 20 years!

Our internal pipe joint seals are a proven solution for pipe joint repairs, pressure pipe repairs, and joint infiltration in drinking water, storm drain sewers, gas pipelines, storage pipelines, distribution pipelines, and power generation pipelines.

    Message Us Directly

    Overview

    HydraTite® is an internal joint sealing system that offers customized mechanical remediation without expensive excavation.

    The system consists of a rubber seal held in place by stainless steel retaining bands. Each seal is custom-made. The seals can be interlocked to span long lengths of pipe, and can include a backing band to remediate pressure piping and cooling water expansion joints.

    PRODUCT PHOTOS

    APPLICATIONS

    Round Pipe Joint Seal
    Repairs deteriorated pipe joints to prevent inflow & infiltration (I&I) and eliminate leaks in pressure applications. Requires man entry size piping, typically 18” and greater.

    Elliptical Pipe Joint Seal
    Repairs defective joints in gravity flow application to eliminate I&I and prevent sinkhole formation. Custom-manufactured to accommodate man entry elliptical pipe sizes.

    Box Joint Seal
    Custom manufactured seal to repair defective joints in box culverts, tunnels, and conduits with rectangular or non-circular cross section. Suitable for gravity and pressure applications.

    Liner End Seal
    Designed to span the termination of internal pipe linings and provide water tight seal to prevent backflow between lines and host pipe. Applicable to sizes 12” and greater provided access to install does not require man entry.

    Expansion Joint Seal
    Designed to replace defective expansion joints. This design allows for the necessary movement that expansion joints require while maintaining a water or air tight seal. Designed to be installed without the need to remove the existing expansion joint.

      Message Us Directly

      KEY FEATURES:

      • Custom made to your projects specifications
      • Repair pipes from the inside, no excavation needed
      • Perform emergency repairs
      • Proven solution for over 20 years, made in the USA

      INDUSTRY USES:

      • Municipal
      • Water & Utilities
      • Power & Utilities
      • Transportation & DOT

      PRODUCT PHOTOS AND VIDEOS

      PRODUCT VIDEOS

      Watch to learn how HydraTite® can help you

      Contact Us Today To Learn More About HydraTite®

      Click on the “get a quote” button at bottom of the page or call

      DOWNLOADS

      RELATED PRODUCTS

      HydraWrap®

      Structural Composite Repair System

      HydraLock®

      Internal Seal For Small-Diameter Pipe

      WaterLine

      Potable Water Pipeline Renewal
